WARN M8000 12V Electric Winch 8000 lb
- 8,000 lb rated line pull, single line (3630 kg)
- 100 ft of 5/16 inch steel wire rope with roller fairlead
- 12 volt, 4.8 hp series wound motor
- 8 ft per minute line speed at rated load
- 216:1 gear ratio, 3-stage planetary gear train
- 10.0 x 4.5 inch mounting bolt pattern
- Remote control on a 12 ft lead
- Limited lifetime warranty
Last refreshed Sep 8, 2026 · Based on the Amazon listing and published specifications, not hands-on testing.
A compact steel rope winch for trucks, Jeeps and SUVs that need recovery pulling power, with a roller fairlead and remote included. It needs a strong battery, and mounting bolts are not listed as part of the box.
As an Amazon Associate I earn from qualifying purchases. ProductDome earns a commission when you buy through links on this page.
ASIN: B000182DYMModel: 26502Category: Winches
Sizes Available
Need a different one? Pick on Amazon →
Overview
On the front of a truck, Jeep or SUV, Warn's compact winch mounts low thanks to its slim profile and suits a range of mounting options. A series wound motor drives a planetary gear train that turns the drum, and steel wire rope feeds through a roller fairlead while a corded remote controls the pull.
Warn pairs a long proven series wound motor with a low profile body, and the steel rope, roller fairlead and remote come together. Owners should plan on a battery that meets the cold cranking amp recommendation, since winching draws hard on it. Mounting hardware is named only by part number, not as part of the box.
Who it's for
Off-roaders running trucks, Jeeps or SUVs who want a steel rope winch with fairlead and remote in one package are the audience. Owners of heavier rigs that need more pull, or anyone set on synthetic line, should look at other models.
Pros and cons
- Roller fairlead included
- Corded remote on a long lead
- Automatic cone brake holds the load
- Freespool clutch for pulling line by hand
- Steel wire rope only on this version
- Needs a strong battery for winching
- Mounting bolts not listed as included
- Listing weight and spec sheet weight disagree
Performance notes
Pulling force comes from the series wound motor multiplied through a multi-stage planetary gear train, which trades drum speed for torque. An automatic cone brake engages to hold the load when the motor stops, and a sliding ring gear clutch disengages the drum for freespooling. Battery condition governs sustained pulls, which is why Warn sets a minimum cold cranking amp rating.
Specifications
| Brand | Warn |
|---|---|
| Model | 26502 |
| Dimensions & fit | |
| Item weight | 74 pounds |
| Product dimensions | 21 × 6.3 × 7.6 inches |
| Drum size | 2.5 inch diameter x 9.0 inch length |
| Capacity & performance | |
| Line speed | 8 feet |
| Power & efficiency | |
| Voltage | 12 volts |
| Battery leads | 2 gauge, 72 inches |
| Recommended battery | 650 CCA minimum |
| Construction & materials | |
| Color | Argent Gray Powder Coat |
| Compatibility & installation | |
| Mounting bolt pattern | 10.0 x 4.5 inches |
| Warranty & support | |
| Warranty | Limited lifetime |
| Other details | |
| Fairlead | Roller |
| Motor | 4.8 hp series wound |
| Gear train | 3-stage planetary |
| Rated line pull | 8,000 lb (3630 kg), single line |
| Brake | Automatic direct drive cone |
| Clutch | Sliding ring gear freespool |
| Gear ratio | 216:1 |
| Wire rope | 100 ft, 5/16 inch diameter steel |
| Remote control | Wired, 12 ft lead |
Frequently asked questions
Does the Warn 26502 come with synthetic rope?
No. This version uses 100 ft of 5/16 inch steel wire rope with a roller fairlead. Warn lists an 80 ft rope and a hawse fairlead on other part numbers.
What battery does the Warn M8000 need?
Warn recommends a battery with at least 650 CCA for winching. The battery leads are 2 gauge and 72 inches long.
Does the Warn M8000 freespool?
Yes. A sliding ring gear clutch lets the drum freespool so line can be pulled out by hand.
How heavy is the Warn M8000 26502?
Warn's spec sheet gives 74 lb for the winch. The product listing shows 83 lb.
